Scope of application of T-slot motor performance test bench: engine laboratory, providing a basic experimental platform for engines, dynamometers, etc., suitable for various inspections, test work, reference planes for precision measurement;

In the overhaul of the cast iron platform, the original design and manufacturing defects found in the use of the cast iron platform, such as unreasonable local design structure, improper design and use of parts and materials, poor overall maintainability, difficult disassembly and assembly,

The load-bearing capacity of the cast iron plate is closely related to the actual design and actual processing and production of the cast iron plate, including the length, width, height, production process, overall structure, weight, material, etc. JB/T7974-99 requirements for cast iron plate.

Counterweight iron, also known as counterweight block, is a process in which metal is smelted into a liquid that meets certain requirements and poured into a mold. After cooling, solidification, and cleaning, a casting with a predetermined shape, size and performance is obtained.

1. Before using cast iron surface plate, it is necessary to have some staff to test and debug the calibration plate, and it can be used after debugging. When installing the flatbed platform, place the bracket supporting the calibration flatbed at the main support point.

The calibration platform is a platform produced with high flatness. The flatness can be divided into 0, 1, 2, and 3 grades according to the standards of the mechanical department. Different precisions are selected according to the degree of inspection work. There are four specific uses of the platform.
